- Ergonomic designed cab with improved overall visibility and well placed controls. They are easy to see, easy to reach and easy to handle.
- Reliable Perkins engine and Carraro wet axles. Power assisted service brakes reduces fatigue. Frame designed for high resistance and efficient load distribution ensuring longer life.
- Easy engine access, convenient placement of key parts and fluid refill points.
355C
Rated Operating capacity:
3060 kg
Rated Power :
36.5 kW (48.9 hp)
355C
Unit：：
- Metric
- U.S
Product Features
355C
355C
355C
355C
Specifications
| Engine Power | 36.5 kW (48.9 hp) |
| Operating Weight | 3060 kg |
| Rated Operation Capacity | 795 kg |
| Raise | 3.8 s |
| Dump | 2 s |
| Lower (empty, float down) | 1.9 s |
| Tipping Load | 1590kg |
| Bucket Breakout Force | 24.5 kN |
| Dump Clearance - Full Height | 2220 mm |
| Dump Reach - Full Height | 540 mm |
| Engine Model Perkins | YCF3050-T307 |
| Emission | EPA Tier 3 / EU Stage IIIA |
| Cooling System | 13 L |
| Overall Length with Standard Bucket | 3432 mm |
| Overall Width with Standard Bucket | 1630 mm |
| Overall Height to top of Cab | 1940 mm |
| Front Clearance Radius with bucket | 1800 mm |
| Bucket capacity | 0.45 m3 |
※For reference only.
